The VAL-EYE-S is a free-standing, floor-mounted emergency eyewash with a 300mm SS304 stainless steel bowl, for areas where workers handle injurious, corrosive or caustic chemicals. It can be activated by hand push board or foot pedal, and complies with ANSI and is SIRIM tested. Eyewash stations should be reachable within 10 seconds of the hazard, approximately 55 feet.
Key Features
- 300mm SS304 stainless steel bowl
- Activation by hand push board or epoxy-coated stainless steel foot pedal
- Chemical-resistant PP spray heads with stainless steel filters
- 42mm stainless steel 201 pipework with red chemical-resistant coating
- Complies with ANSI; SIRIM tested
Specifications
| Model | VAL-EYE-S |
|---|
| Type | Floor-mounted eyewash |
|---|
| Bowl | 300mm, SS304 stainless steel |
|---|
| Pipe & Fittings | 42mm stainless steel 201, red coating |
|---|
| Valve | 1/2" BSP ball valve with push board |
|---|
| Water Inlet / Outlet | 1/2" / 1" BSP |
|---|
| Water Pressure | 0.2–0.6MPa |
|---|
| Compliance | ANSI; SIRIM tested |
|---|
Applications
Chemical plants, production floors, warehouses storing hazardous goods, and laboratories without suitable wall space.
